28 amp Relay (replaces all relays, requires large transformer)

The Hide-A-Hose MD 28 amp Relay (replaces all relays, requires large transformer) is a heavy-duty replacement relay for central vacuum electrical systems. Built In Vacuum says it replaces the smaller #240 and #241 relays and works with 110 to 240 volt motors and all mini breakers. It is specifically intended for systems using a large 24-volt transformer, and the company is very explicit that this relay only works with large 24-volt transformers.

Key Features:

• Heavy-duty 28 amp relay for central vacuum electrical repairs.
• Replaces older smaller relays #240 and #241.
• Works with 110 to 240 volt motors.
• Compatible with all mini breakers.
• Requires a large 24-volt transformer only; Built In Vacuum says it will not work with smaller transformers.
• Large transformer options called out on the page are part #232 for 110–120 volt systems and part #231L for 220–240 volt systems.
• Must be mounted right side up with the sticker/wording pointing up.
• Wiring diagrams are provided for single motor, dual motor under 16 amps, and dual motor over 16 amps applications.
• Replaces Omron relays and carries manufacturer number DP2020A5021.

Specifications:

• Brand: Hide-A-Hose / MD.
• Product Name: 28 amp Relay (replaces all relays, requires large transformer).
• SKU / Part Number: 242.
• Product Type: Central vacuum relay / electrical replacement part.
• Amp Rating: 28 amp.
• Voltage Compatibility: 110 to 240 volt motors.
• Transformer Requirement: Large 24-volt transformer only.
• Compatible Transformer Part Numbers: #232 for 110–120V, #231L for 220–240V.
• Breaker Compatibility: All mini breakers.
• Mounting Space Required: 4 x 2.5 inches.
• Wire Guidance: 14 or 16 gauge wire for typical applications; 12 gauge wire for dual motor setups over 17 amps.
• Manufacturer Number: DP2020A5021.
