28 amp Relay Bracket

The Hide-A-Hose MD 28 amp Relay Bracket is a mounting bracket made specifically for the #242 28 amp relay. Built In Vacuum explains that the 28 amp relay must be mounted right side up to operate properly, and this “C” bracket solves upside-down relay applications found in some MD, SilentMaster, and FloMaster central vacuum units, along with a few others. The relay itself is sold separately.

Key Features:

• Designed for the #242 28 amp relay.
• Helps correct upside-down relay applications by positioning the relay properly.
• Required because the 28 amp relay must be mounted right side up to work.
• Useful for some MD, SilentMaster, and FloMaster central vacuum systems, plus some others.
• Includes two bottom mounting feet for screw-down installation.
• Relay is not included.

Specifications:

• Brand: Hide-A-Hose / MD. This is the site brand context for the listed part.
• Product Name: 28 amp Relay Bracket.
• SKU / Part Number: 8620000MBR.
• Product Type: Relay mounting bracket.
• Intended Use: Mounts the #242 28 amp relay in the correct upright position.
• Space Required for Installation: 3 x 5 inches.
• Mounting Note: Uses two bottom feet with screws to secure bracket and relay to the vacuum. Screws are not included.
• Relay Inclusion: Relay sold separately.
